Cisco UCS C24 M3 High-Density SFF Rack-Mount Server
CONFIGURING the SERVER
15
Approved Configurations
■ For 24-drive backplane with expander systems
— Select one of the following plug-in PCIe RAID controllers from Table 5.
• LSI MegaRAID 9265CV-8i (supports up to 24 drives)
• LSI MegaRAID 9240-8i or LSI MegaRAID 9220-8i controller (support up to 16 drives)
Caveats
■ There are two full-height PCIe slots available on riser 1 and three half-height PCIe slots
available on riser 2.
RAID Configuration Options
R2XX-RAID0 Factory preconfigured RAID striping option
Enable RAID 0 Setting. Requires a minimum of one hard drive.
R2XX-RAID1 Factory preconfigured RAID mirroring option
Enable RAID 1 Setting. Requires exactly two drives with the same size, speed,
capacity.
R2XX-RAID5 Factory preconfigured RAID option
Enable RAID 5 Setting. Requires a minimum of three drives of the same size,
speed, capacity.
R2XX-RAID6 Factory preconfigured RAID option
Enable RAID 6 Setting. Requires a minimum of four drives of the same size,
speed, capacity.
R2XX-RAID10 Factory preconfigured RAID option
Enable RAID 10 Setting. Requires an even number of drives (minimum of four
drives) of the same size, speed, capacity.
NOTE: Although RAID levels 50 and 60 are not orderable from the factory, they are
supported for selected controllers as shown in
Table 5.
NOTE: No RAID factory preconfigured RAID option can be chosen (a factory RAID
volume cannot be configured) if:
■ there are no drives, or
■ SAS and SATA drives are mixed, or
■ different capacity drives are mixed
Table 5 Available Plug-In Card RAID Options (continued)
Product ID (PID) PID Description
