Supported DIMM Populations
The supported DIMM populations are listed in Table 24.
Table 24 Supported DIMM Configurations
CPU 1 DIMMs
# CPU 1
DIMMs
CPU 1
Capacity
CPU 2 DIMMs
# CPU 2
DIMMs
CPU 2
Capacity
Tota l
DIMMs for
both CPUs
Tota l
Capacity
for 2
CPUs
1 x 4 GB 1 4 GB 1 x 4 GB 1 4 GB 2 8 GB
2 x 4 GB 2 8 GB 2 x 4 GB 2 8 GB 4 16 GB
1 x 8 GB 1 8 GB 1 x 8 GB 1 8 GB 2 16 GB
3 x 4 GB 3 12 GB 3 x 4 GB 3 12 GB 6 24 GB
4 x 4 GB 4 16 GB 4 x 4 GB 4 16 GB 8 32 GB
2 x 8 GB 2 16 GB 2 x 8 GB 2 16 GB 4 32 GB
1 x 16 GB 1 16 GB 1 x 16 GB 1 16 GB 2 32 GB
5 x 4 GB 5 20 GB 5 x 4 GB 5 20 GB 10 40 GB
6 x 4 GB 6 24GB 6 x 4 GB 6 24GB 12 48 GB
3 x 8 GB 3 24 GB 3 x 8 GB 3 24 GB 6 48 GB
4 x 8 GB 4 32 GB 4 x 8 GB 4 32 GB 8 64 GB
2 x 16 GB 2 32 GB 2 x 16 GB 2 32 GB 4 64 GB
3 x 8 GB + 3 x 4 GB
1
Notes . . .
1. UCS-MR-1X082RY-A + UCS-MR-1X041RY-A
6
36 GB
3 x 8 GB + 3 x 4 GB
2
2. UCS-MR-1X082RY-A + UCS-MR-1X041RY-A
6
36 GB
12 72 GB
5 x 8 GB 5 40 GB 5 x 8 GB 5 40 GB 10 80 GB
6 x 8 GB 6 48 GB 6 x 8 GB 6 48 GB 12 96 GB
3 x 16 GB 3 48 GB 3 x 16 GB 3 48 GB 6 96 GB
3 x 16 GB + 3 x 4 GB
3
3. UCS-MR-1X162RY-A + UCS-MR-1X041RY-A
6
60 GB
3 x 16 GB + 3 x 4 GB
4
4. UCS-MR-1X162RY-A + UCS-MR-1X041RY-A
6
60 GB
12 120 GB
4 x 16 GB 4 64 GB 4 x 16 GB 4 64 GB 8 128 GB
3 x 8 GB + 3 x 16 GB
5
5. UCS-MR-1X082RY-A + UCS-MR-1X162RY-A
6
72 GB
3 x 8 GB + 3 x 16 GB
6
6. UCS-MR-1X082RY-A + UCS-MR-1X162RY-A
6
72 GB
12 144 GB
5 x 16 GB 5 80 GB 5 x 16 GB 5 80 GB 10 160 GB
6 x 16 GB 6 96 GB 6 x 16 GB 6 96 GB 12 192 GB
