Cisco UCS C24 M3 High-Density SFF Rack-Mount Server
14
CONFIGURING the SERVER
STEP 4 SELECT RAID CONFIGURATION
For the 24-drive version of the server, the RAID controller choices are:
(1) One plug-in RAID controller card.
Cisco can provide factory-configured RAID systems depending on the RAID controller chosen and
the number of drives ordered. Factory-configured RAID options are listed in
Tab le 5 along with
each RAID card description. RAID levels 50 and 60 are supported, although they are not available
as factory-configured RAID options.
Select RAID Controller Options
Select one RAID controller and an appropriate RAID configuration option listed in Table 5.
NOTE: The 24-drive version of the server does not support embedded RAID, which is
normally installed on the motherboard and does not consume a PCIe slot. The only
RAID support available is through a plug-in RAID controller PCIe card.
Table 5 Available Plug-In Card RAID Options
Product ID (PID) PID Description
RAID Controllers
UCS-RAID-9265CV LSI MegaRAID 9265CV-8i (with SuperCap power backup)
■ Supports up to 24 internal SAS or SATA drives. SAS and SATA drives can be
mixed.
■ Includes a 1 GB Transportable Memory Module (TMM) cache and SuperCap
power module for data cache backup
■ RAID levels supported: RAID 0, 1, 10, 5, 50, 6, 60 (see the RAID
Configuration Options section later in this table)
UCSC-RAID-9240-8I LSI MegaRAID 9240-8i
■ Supports up to 16 internal SAS or SATA drives with the 24-drive backplane
plus expander option. SAS and SATA drives can be mixed.
■ No data cache backup. There is no direct attached buffer memory. The
controller utilizes system RAM for buffer cache memory.
■ RAID levels supported: RAID 0, 1, 10, 5, 50 (see the RAID Configuration
Options section later in this table)
UCSC-RAID-9220-8I LSI MegaRAID 9220-8i
■ Supports up to 16 internal SAS or SATA drives with the 24-drive backplane
plus expander option. SAS and SATA drives can be mixed.
■ No data cache backup. There is no direct attached buffer memory. The
controller utilizes system RAM for buffer cache memory.
■ RAID levels supported: RAID 0, 1, 10 (see the RAID Configuration Options
section later in this table)
