Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
18
CONFIGURING the SERVER
Approved Configurations
(1) 1-CPU configuration without memory mirroring:
■ Select from 1 to 12 DIMMs. Refer to Memory Population Rules, page 66, for more detailed
information.
(2) 1-CPU configuration with memory mirroring:
■ Select 2, 4, 6, 8, or 12 identical DIMMs. The DIMMs will be placed by the factory as shown in
the following table.
■ Select the memory mirroring option (N01-MMIRROR) as shown in Tabl e 4 on page 17.
(3) 2-CPU configuration without memory mirroring:
■ Select from 1 to 12 DIMMs per CPU. Refer to Memory Population Rules, page 66, for more
detailed information.
Total
Number
of
DIMMs
CPU 1 DIMM Placement in Channels
(for
identical DIMMs)
Blue Slot
(Slot 1)
Black Slot
(Slot 2)
Black Slots
(Slot 3)
2 (A1, B1) — —
4 (A1,B1); (C1,D1) — —
6
1
Notes . . .
1. Not recommended (for performance reasons)
(A1,B1, C1) (A2, B2, C2) —
8 (A1,B1); (C1,D1) (A2,B2); (C2,D2) —
12
2
2. If this 3DPC configuration is implemented with quad-rank DIMMs (the 32 GB LR DIMM), the
maximum DIMM speed will be 1066 MHz, even though the DIMM is specified to operate at a higher
speed.
(A1,B1); (C1,D1) (A2,B2); (C2,D2) (A3,B3); (C3,D3)

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
