Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
19
(4) 2-CPU configuration with memory mirroring:
■ Select 2, 4, 6, 8, or 12 identical DIMMs per CPU. The DIMMs will be placed by the factory as
shown in the following table.
■ Select the memory mirroring option (N01-MMIRROR) as shown in Tabl e 4 on page 17.
Number
of
DIMMs
per CPU
CPU 1 DIMM Placement in Channels
(for
identical DIMMs)
CPU 2 DIMM Placement in Channels
(for
identical DIMMs)
Blue Slots Black Slots Black Slots Blue Slots Black Slots Black Slots
2 (A1, B1) — — (E1, F1) — —
4 (A1,B1);
(C1,D1)
— — (E1,F1);
(G1,H1)
— —
6
1
Notes . . .
1. Not recommended (for performance reasons)
(A1,B1, C1) (A2, B2, C2) — (E1,F1, G1) (E2, F2, G2) —
8 (A1,B1);
(C1,D1)
(A2,B2);
(C2,D2)
— (E1,F1);
(G1,H1)
(E2,F2);
(G2,H2)
—
12
2
2. If this 3DPC configuration is implemented with quad-rank DIMMs (the 32 GB LR DIMM), the maximum DIMM
speed will be 1066 MHz, even though the DIMM is specified to operate at a higher speed.
(A1,B1);
(C1,D1)
(A2,B2);
(C2,D2)
(A3,B3);
(C3,D3)
(E1,F1);
(G1,H1)
(E2,F2);
(G2,H2)
(E3,F3);
(G3,H3)
NOTE: System performance is optimized when the DIMM type and quantity are
equal for both CPUs, and when all channels are filled equally across the CPUs in the
server.

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
