Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
34
CONFIGURING the SERVER
Approved Configurations
(1) No PCIe RAID controller
■ If you did not choose a PCIe RAID controller (for example, you are using embedded RAID or a
mezzanine RAID controller), you can select up to three PCie option cards listed in
Table 11
for a 1-CPU system or up to five for a 2-CPU system.
(2) One PCIe RAID controller card
■ If you selected one PCIe RAID controller, you can select up to two of the optional PCIe cards
listed in
Table 11 for a 1-CPU system or up to four for a 2-CPU system.
(3) Two PCIe RAID controllers
■ If you selected two PCIe RAID controllers (only supported in 16 HDD backplane 2-CPU
systems), you can select three of the optional PCIe cards listed in
Table 11.
Caveats
■ For 1-CPU systems:
— Only the three PCIe slots on PCIe riser 1 are available. The three slots are full-height
PCIe slots 1, 2, and 3 (see
Figure 3 on page 7). These are the three slots on the
right when looking at the rear of the server.
— Neither the PCIe riser 2 (with the two PCIe slots numbered PCIe 4 and PCIe 5, at the
left when viewing the server from the rear) nor the mezzanine card are supported
on 1-CPU systems.
— Only a single VIC card (the half-height Cisco VIC 1225 PCIe card) may be installed on
a 1-CPU system, and it must be installed in slot 2 of riser 1. See
Table 1 on page 8
for the slot descriptions.
N2XX-AQPCI05 QLogic QLE2562 Dual Port 8Gb Fibre Channel HBA Half
UCSC-PCIE-Q2672 Qlogic QLE2672-CSC, 16Gb Fibre Channel HBA with SR Optics Half
UCSC-PCIE-E16002 Emulex LPe16002-M6, 16Gb Fibre Channel HBA with SR Optics Half
UCS Storage Accelerators
UCSC-F-FIO-3000M Cisco UCS 3.0 TB MLC Fusion ioDrive2 for C-Series Servers Full
UCSC-F-FIO-1205M Cisco UCS 1205 GB MLC Fusion ioDrive2 for C-Series Servers Half
UCSC-F-FIO-785M Cisco UCS 785 GB MLC Fusion ioDrive2 for C-Series Servers Half
UCSC-F-FIO-365M Cisco UCS 365GB MLC Fusion ioDrive2 for C-Series Servers Half
Table 11 Available PCIe Option Cards (continued)
Product ID (PID) PID Description
Card
Height

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
