Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
42
CONFIGURING the SERVER
Caveats
■ The V01 server version requires ordering a GPU upgrade kit (two PCIe risers, brace, “Y”
power cable, straight power cable, and power cable adapter). The V02 server version
requires ordering a “Y” power cable to support two GPUs or a straight power cable to
support a single GPU. The power cable plugs into the motherboard GPU power connector
and to the appropriate GPU(s).
■ Slot 5 is the preferred slot for the first GPU.
■ If two GPUs are installed, a VIC card cannot be selected because a VIC card can only be
plugged into either slot 2 or slot 5 in a 2-CPU system.
CAUTION: When using dual NVIDIA Tesla GPU cards, you must preserve at
least 10 mm of space between servers to ensure adequate airflow and cooling.
CAUTION: When using NVIDIA Tesla GPU cards, the operating temperature
range is 32° to 95°F (0° to 35°C).
NOTE: Mixing different GPU cards in the same server is not supported.
NOTE: All GPU cards require two CPUs and two 1200 W power supplies in the server.
Table 17 NVIDIA Tesla GPU Population Rules by Server Version
C240 M3 Server
Version
Single Tesla GPU Dual Tesla GPUs
Server version V01 Slot 5 Not supported
Server version V02 Slot 5 Slots 2 and 5
NOTE: To discover your chassis version (V01 or V02), look at the label on the top left
side of the chassis (see
Figure 6 on page 43). The version number (V01 or V02) is
shown in the label.
NOTE: See Figure 7 on page 63 for the location of the 8-pin GPU power connector
on the motherboard. Connect cable(s) as appropriate from this connector to the
power connector on the GPU(s).

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
