3-65

Cisco UCS C240 Server Installation and Service Guide

OL-25761-01z

Chapter 3 Maintaining the Server

Replacing an Internal SD Card

Figure 3-37 Replacing a BBU or SCPM RAID Backup Unit

1 RAID backup unit mounting points on

removable air baffle

331851
