Cisco UCS C240 User Manual

A-3
Cisco UCS C240 Server Installation and Service Guide
OL-22326-01
Appendix A Server Specifications
Power Specifications
930W DC Power Supply
Table A-4 lists the specifications for each 930 W DC power supply (Cisco part number
UCSC-PSU-930WDC).
Table A-4 930 W DC Power Supply Specifications
Description Specification
Class RSP1
Input
DC input voltage range –48 to -60 VDC nominal
(self-ranging, –40 to –72 VDC)
DC line input current (steady state) 23 A peak at –48 VDC
Output
12 V main power output 930 W
12 V standby power output 30 W
Power supply output voltage Main power: 12 VDC
Standby power: 12 VDC

Cisco UCS C240 Specifications

General

Management	Cisco Integrated Management Controller (CIMC)
Form Factor	2U Rack
Memory	Up to 3TB DDR4
Storage	Up to 24 x 2.5-inch or 12 x 3.5-inch SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swappable power supplies (various wattage options)
