Cisco WAP150 User Manual

• Radio
• IEEE 802.11 Mode
• Channel Bandwidth
• Channel (Auto is not recommended)
See Radio, on page 47 (Basic Settings) for information on configuring these settings.
• Work Group Bridge mode currently supports only IPv4 traffic.
• Work Group Bridge mode is not supported across a Single Point Setup.
To configure Work Group Bridge mode:
Step 1 Select Wireless Bridge.
Step 2 Click WorkGroup.
Step 3 Select the WGB Port to which the configuration parameters will be applied.
Step 4 Click edit to configure the following parameters for the Infrastructure Client Interface (Uplink / Downlink):
Table 1: Infrastructure Client Interface (Uplink / Downlink)
DownlinkUplinkWGB Port
Check the check box to enable the
Infrastructure Client Interface.
Check the check box to enable the
Infrastructure Client Interface.
Enabled
Specifies the Radio Id (Radio 1 (2.4 GHz) or
Radio 2 (5GHz)).
Specifies the Radio Id (Radio 1 (2.4 GHz) or
Radio 2 (5GHz)).
Radio
The SSID for the Access Point Interface cannot
be the same as the Infrastructure Client SSID.
Specifies the current SSID of the BSS.
There is an arrow next to SSID for
SSID Scanning. This feature is
disabled by default, and is enabled
only if AP Detection is enabled in
Rogue AP Detection (which is also
disabled by default).
Note
SSID
The type of security to use for authenticating.
The options are:
• None
• WPA Personal
The type of security to use for authenticating
as a client station on the upstream WAP
device. It can be one of the following:
• None
• WPA Personal
• WPA Enterprise
Encryption
Not Applicable (N/A)Indicates whether the WAP is connected to the
upstream WAP device.
Connection Status
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
66
Wireless Bridge
WorkGroup Bridge

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
