Cisco WAP150 User Manual

Cisco Umbrella 105
CHAPTER 9
Cisco Umbrella 105
Monitor 107
CHAPTER 10
Dashboard 107
LAN Status 108
Wireless Status 109
Traffic Statistics 110
Single Point Setup Status 110
Clients 111
Guests 113
Troubleshoot 115
CHAPTER 11
Spectrum Intelligence 115
Packet Capture 115
Local Packet Capture 116
Remote Packet Capture 117
Stream to a Remote Host 117
Stream to CloudShark 118
Wireshark 119
Packet Capture File Download 121
Using HTTP 121
Support Information 121
Download CPU/RAM Data 122
DeAuthentication Message Reason Codes 123
APPENDIX A
Deauthentication Message Reason Codes 123
Deauthentication Reason Code Table 123
Where to Go from Here 125
APPENDIX B
Where to Go from Here 125
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
ix
Contents

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
