To monitor all VLANs on the trunk port, use the no monitor session session_number filter global
configuration command.
This example shows how to remove any existing configuration on SPAN session 2, configure SPAN
session 2 to monitor traffic received on Gigabit Ethernet trunk port 2, and send traffic for only VLANs
1 through 5 and VLAN 9 to destination Gigabit Ethernet port 1.
Switch(config)# no monitor session 2
Switch(config)# monitor session 2 source interface gigabitethernet0/2 rx
Switch(config)# monitor session 2 filter vlan 1 - 5 , 9
Switch(config)# monitor session 2 destination interface gigabitethernet0/1
Switch(config)# end
Configuring RSPAN
These sections contain this configuration information:
• RSPAN Configuration Guidelines, page 23-16
• Configuring a VLAN as an RSPAN VLAN, page 23-16
• Creating an RSPAN Source Session, page 23-17
• Creating an RSPAN Destination Session, page 23-19
• Creating an RSPAN Destination Session and Configuring Incoming Traffic, page 23-20
• Specifying VLANs to Filter, page 23-21
Step 5
monitor session session_number
destination {interface interface-id [, | -]
[encapsulation {dot1q | replicate}]}
Specify the SPAN session and the destination port (monitoring port).
For session_number, specify the session number entered in Step 3.
For interface-id, specify the destination port. The destination interface
must be a physical port; it cannot be an EtherChannel, and it cannot
be a VLAN.
(Optional) [, | -] Specify a series or range of interfaces. Enter a space
before and after the comma; enter a space before and after the hyphen.
(Optional) Enter encapsulation dot1q to specify that the destination
interface uses the IEEE 802.1Q encapsulation method.
(Optional) Enter encapsulation replicate to specify that the
destination interface replicates the source interface encapsulation
method. If not selected, the default is to send packets in native form
(untagged).
Step 6
end Return to privileged EXEC mode.
Step 7
show monitor [session session_number]
show running-config
Verify the configuration.
Step 8
copy running-config startup-config (Optional) Save the configuration in the configuration file.
