Cisco WS-C2960-24LC-S User Manual

28-10
Catalyst 2960 Switch Software Configuration Guide
OL-8603-04
Chapter 28 Configuring QoS
Understanding QoS
Figure 28-4 shows the policing and marking process.
Figure 28-4 Policing and Marking Flowchart on Physical Ports
86835
Ye s
Ye s
No
No
Pass
through Drop
Mark
Get the clasification
result for the packet.
Is a policer configured
for this packet?
Check if the packet is in
profile by querying the policer.
Check out-of-profile action
configured for this policer.
Drop packet.
Modify DSCP according to the
policed-DSCP map. Generate
a new QoS label.
Start
Done
