63
Chapter 3 Printer Adjustments
Ribbon Balance Adjustment
Do this adjustment by turning the front ribbon left-right balance
adjustment knob. If the ribbon is wrinkled, adjust it as follows. The scale is
usually aligned with the center.
Front ribbon left-right
balance adjustment knob
1. Look at the ribbon from font side and check on which side
(adjustment knob side /the side opposite to the adjustment
knob) loose is present between the ribbon on the feeding
side and ribbon guide shaft on the back side.
Checking which side is loose.
Adjusting the Ribbon
Self Print Mode (p.34)
To Next Page
