88
Appendixes
Replacing the Interface Board
Replacement Method
1. Remove the screws (2 nos) that the xing the interface cover.
Screw
Interface cover
Rear Side
2. Insert the interface port into the slot, and connect to the
interface connector inside the printer.
Interface Board
Interface connector
Rear Side
Always turn o the power to the printer before replacing the
interface board. Do not pull it out with unnecessary force. This will
cause an accident.
Caution
To Next Page
