CITROEN C1 - Page 59

53
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engine : CFA
MPERATIVE : Respect the safety and cleanliness requirements.
Removing.
Raise and support the vehicle, wheels hanging.
Disconnect the battery negative cable (see corresponding operation).
Drain the engine oil (see corresponding operation).
Drain the gearbox oil (see corresponding operation).
Drain the cooling circuit (see corresponding operation).
Remove the auxiliary drive belt (see corresponding operation).
Remove the sump.
Remove the driveshafts (see corresponding operation).
Remove the engine-gearbox assembly (see corresponding operation).
Move aside the elastic clip on the coolant pump.
Remove the alternator (see corresponding operation).
Remove the screw and the guide-tube of the oil gauge.
Remove the O-ring seal on the guide-tube of the oil gauge.
B1D201MD
B1D201ND
