54
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engine : CFA
Disconnect the camshaft position sensor.
Remove the screw and the crankshaft position sensor
Remove the 13 screws and the 2 nuts in the sequence indicated.
Remove the valve cover with its gasket.
Remove the valve cover gasket
B1D201QD
B1D201RD
