160
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engines: KFW - NFV
Pre-tensioning the timing belt (continued).
- Make sure of the timing setting by refitting the pegs [1] and [2].
- Remove the valve cover.
- Position the tool [5] (respect the direction of fitting relative to the valve timing).
Adjusting the belt tension.
- Place tool [4] on the tensioned part of the belt.
- Slacken the nut (2).
- Detension the belt, but too much.
- Tension the timing belt to obtain a value of:
31 ± 2 SEEM units.
- Tighten the nut (2) to 2 m.daN.
- Remove tools [1], [2], [4] and [5].
Checking the belt tension.
- Rotate the crankshaft 2 turns in the normal direction of rotation.
- Check that it is still possible to peg the following components.
- Flywheel.
- Camshaft.
IMPERATIVE: Repeat the belt tensioning operation if the pegging is not possible.
XSARA - XSARA PICASSO
