ENGINE
183
CHECKING AND SETTING THE VALVE TIMING
Engine: RFS
- Tension to: (Pulleys slackened).
- Tighten the screw of the roller
(7) to 2 m.daN.
- Fit the tool [4].
- Tighten the screws (10) to 7.5 m.daN.
- Remove the tools.
- Rotate the crankshaft by two turns
(normal direction of rotation).
- Check the pegging of the crankshaft/camshaft using tools [2] and [3].
NOTE: Tools [2] and [3] should slide in easily.
- Remove the tools.
B1EP121CB1EP120C
Engine
New belt
RFS
35 SEEM units
XSARA
