AXLES
SUSPENSION
STEERING
Steering Rack pinion Number of teeth Number of steering Turning circle Turning circle
rack travel in rack wheel turns between walls between kerbs
Left hand drive
71,7 x 2
LH helix
28 Teeth 3,22 12 m 11,48 m
Right hand drive
RH helix
Engines Steering valve
NFV - 6FZ - RFN - RHY number of teeth :7
Length of the steering link rods (pre-adjustment):
- Between ball-joint centres = 392 mm.
- Between the centre of the pivot ball-joint and the contact face of the steering rack ball-joint = 412 mm.
STEERING COLUMN SPECIFICATIONS XSARA PICASSO
