CLA-VAL D35
Communicating Valve Controller
CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 5 - D35001UE - 08/22
© Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish
2 D35 CHARACTERISTICS
(1) Body with or without internal battery (according to version)
(2) D35 Head (main board + front panel)
(3) Antenna
(A) SIM Card connector
(B) SD Card connector
(C) Battery connector
(D) Micro USB Connector
(E) Tag connect (8 pin)
(F) Memory battery coin holder coin
3 WIRING CHARACTERISTICS
Refer to the D3500 wiring diagram for connection details.
Refer to the latest wiring diagram for the correct wiring!
Figure 1 D35 parts
Figure 2 D35 interfaces
