Clack WS1 25CI Series - Water Meter, Meter Plug and Mixing Valve

WS1CI & WS1.25CI Manual Page 37
Water Meter, Meter Plug and Mixing Valve
3
4
5
1
2
6
Drawing No. Order No. Description Quantity
1 V3151 WS1 Nut 1” QC 1
2 V3003* WS1 Meter ASY 1
3 V3118-01 WS1 Turbine ASY 1
4 V3105 O-ring 215 1
5 V3003-01 WS1 Meter Plug ASY 1
6 V3013 Mixing Valve optional
*Order number V3003 includes V3118-01 WS1 Turbine ASY and V3105 O-ring 215.
