11
CLAGE
Tlaková instalace (uzavřená) s
armaturou pro běžné tlakové
použití
Unvented installation (closed
outlet) with tap for pressu-
rised appliances
6. Typická montáž 6. Typical installations
4
Perlátor / regulátor průtoku:
Fit jet regulator:
MCX 3/4: CSP 3
MCX 6/7: CSP 6
Elektro připojení s přívodním
kabelem (možno zkrátit).Electrical
connection with mains power cable
(shorten if necessary)
Rohový ventil ca. 550 / Angle valve approx. 550
Horní hrana umyvadla ca. 850 / Top edge of wash basin approx.. 850
Osa držáku ca. 520 / Axis wall bracket approx. 520
Kabelová průchodka ca. 553 / Cable entry approx.
Rohový ventil G 3/8“
Angle valve G 3/8“
Rozměry v mm Dimensions in mm
