Clarion NP509 User Manual

57
Symbol Description
This value appears on the map screen in the Trip Data area. This is the value at the
bottom.
4.1.7.1 Trip Computer screen
The Trip Computer screen provides collected trip data. It can be opened from the Trip Information
screen by tapping
.
The fields on this screen are continuously updated while you keep the screen open.
You can switch between the trips, pause then resume them, or reset their data.
You have the following functions on this screen:
Button Description
Pauses the trip currently shown on the screen. Values on the screen stop
changing.
This button replaces the previous one if it has been activated. Tap it to resume
collecting trip data.
Resets all counters of the currently shown trip. Collecting trip data is restarted only
when Clarion Mobile Map receives a position from the GPS.
,
Cycles through all trips.
4.1.8 Quick menu
The Quick menu is a selection of controls that are frequently needed during navigation. It can be
opened directly from the Map screen by tapping
.
If you tap any of the switches in the Quick menu except for the Vehicle type, the Map screen
immediately returns. A switch is on if its lamp is lit. The Vehicle type button is different. It is a multi-
value button. It opens a list of available choices, and the symbol of the selected vehicle is shown on
the button.
Button Main function (single tap) Function (tap and hold)
Master Volume
slider
Adjusts the sound volume of the device.
A
ll sounds
of the application are affected.
n/a
If you only adjust the volume, you need to use this
button to return to the Map screen.
Opens the Navigation menu.
Mutes all sounds of Clarion Mobile Map. Opens Sound settings.
