5. After a short summary of the route parameters, the map appears showing the entire route. The
route is automatically calculated. Tap
to modify route parameters, or tap
and start your journey.
Note!
The alternative way to search for a Place is to tap the
button in the Quick menu or the
button in the Destination menu. These alternatives are different from the Combined
Search. The first one is also a name search but i
f there is a route planned, it will not be carried
out around your current location but along the route. The Place search in the Destination menu
is a complex Place search with several options including category search or search around the
destination of t
he current route.
3.1.1.6 Combined Search - Navigating to a Place of Interest by its category
To find a Place of Interest in Combined Search by giving its category only, carry out the search as
described earlier. Search for a part of the category name. When you get to the result screen, do as
follows:
1. The list is ordered with Place categories at the beginning but if you want, you can filter the list to
contain Place categories only. Tap
at the top of the screen to filter the list.
2. Scroll the list and select one of the categories. You get the list of Places in that category ordered
by their distance from your current position. If the selected category contains subcategories, you
will see all Places in that category mixed into one list.
3. Scroll down the list if necessary and then select one of the Places from the list.
4. Once the destination is selected, a full screen map appears with the selected point in the middle. If
necessary, tap the map somewhere else to modify the destination. The Cursor (
) appears at
the new location. Tap
to confirm the destination, or tap to
select a different destination.
NX404 English 33
