Clarion NX404 Quick Start Guide & Installation Manual

57
NX404
English
English
Owner’s Manual
Ye l l o w
Blac
k
Purple
Purple Bla
ck
Grassgreen
Gray
Gray Bla
ck
White
White Bla
ck
Green
Green Blac
k
Blue White
Orange White
Red
Brown
Blue
V
Ground
Rear right 
Rear right 
Parking brake cord
Purple Whit
e
Reverse gear cord
Front right 
Front right 
Front left

Front left

Rear left
Rear left
Amplifier tu
r
n on cord
Illumination
V accessory
Phone interr
upt
Auto antenna
Connect directly
to battery
1RWH
*1: Connecting the PHONE INTERRUPT terminal
The phone interrupt will mute the audio if the lead receives a negative or ground signal.

Clarion NX404 Specifications

General

MP3 playback	Yes
CD-R playback	-
Audio formats supported	MP3
Video formats supported	DIVX
USB version	2.0
Line outputs (RCA)	6
USB ports quantity	2
DIN size	2 DIN
Output power	72 W
Product color	Black
Disc types supported	DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Maximum power per channel	18 W
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	93 dB
AM band range	530 - 1710 kHz
FM band range	87.9 - 107.9 MHz
Supported radio bands	AM, FM
Aspect ratio	17:9
Display type	TFT
Display diagonal	6.2 \
Output power description	4 x 18

Weight and Dimensions

Weight	2268 g
Dimensions (WxDxH)	178 x 172 x 100 mm
