Clarion Ungo Pro Security RK1 Installation Guide

12
remote start harness (H3) wiring diagram
______
______
______
______
______
door lock harness (H4) wiring diagram
______
______
______
remote start auxiliary harness wiring diagram
______
______
______
______
PURPLE (-) 200 mA STARTER RELAY OUTPUT
PINK (-) 200 mA IGNITION RELAY OUTPUT
ORANGE (-) 200 mA ACCESSORY RELAY OUTPUT
BLUE (-) 200 mA STATUS OUTPUT
1
2
3
4
BLUE (+) LOCK (-) UNLOCK
NO FUNCTION
GREEN (-) LOCK (+) UNLOCK
H4/1
H4/2
H4/3
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
VIOLET/WHITE TACHOMETER INPUT WIRE
BROWN (+) BRAKE SWITCH SHUTDOWN WIRE
GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE
BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER - LATCHED/PULSED
H3/1
H3/2
H3/3
H3/4
H3/5
