1)
Press
the
EQ
button
[14]
to
go
to
the
equaliz-
er
mode.
2)
Press
the
BAND
button
to
select
EQ
BASIC
or
EQ
USER.
Each
time
you
press
the
BAND
button
[8],
the
EQ
BASIC
and
EQ
USER
toggles.
-
EQ
BASIC:
This
menu
consists
of
the
6
equal-
izer
characteristics
initially
set.
EQ
USER:
The
menu
containing
user-set
equalizer
characteristics
(for
set-
ting
the
characteristics,
see
the
next
subsection
“Setting
and
storing
the
equalizer
characteris-
tics”.
The
equalizer
No.
where
no
setting
is
made
becomes
flat.)
3)
Press
No.
1
to
6
of
the
Preset
buttons
[9]
io
select
the
equalizer
characteristic
to
be
set.
No.1
|
BAS
Bass
is
US1
(BASS
BOOST)
emphasized.
No.2
|HIG
Treble
is
US2
(HIGH
BOOST)
emphasized.
No.3
{ACO
Mean
(human
US3
(ACOUSTICAL)
voice)
is
emphasized.
IMP(IMPACT)
Bass
and
US4
treble
are
emphasized.
US5
US6
SMO
Sound
level
of
(SMOOTH)
each
band
is
smoothed.
FLA(FLAT)
Original
sound
(flat
equalizing)
Note:
e
Turn
on
the
equalizer
effect
after
following
the
instructions
in
the
next
subsection
“Turning
on
and
off
the
equalizer
effect”.
Otherwise,
the
above
set-
tings
will
be
invalidated.
Turning
on
and
off
the
equalizer
effect
1)
Press
the
ADJ
button
[15]
to
go
to
the
CON-
FIGURATION
mode.
2)
Slide
the
o-selector
[1]
to
W
(down)
or
A
(up)
to
move
the
cursor
to
“EQ”.
3)
Slide
the
o-selector
[4]
to
(right)
to
turn
“OFF”
and
“ON”.
4)
Press
the
ADJ
button
[15]
to
return
to
the
pre-
vious
mode.
Operating
the
DSP
and
Equalizer
Setting
and
storing
the
equalizer
characteristics
You
can
set
your
own
equalizer
characteristics
and
store
them
to
“EQ
USER’
(US1
to
US6).
Up
to
6
patterns
can
be
stored.
Notes:
e
This
setting
cannot
be
edited
when
EQ
in
the
CONFIGURATION
display
is
turned
off.
e
/f
the
control
is
idle
for
about
5
seconds
after
each
operation,
the
unit
returns
to
the
previous
mode.
1)
Press
the
EQ
button
[14]
to
go
to
the
equaliz-
er
mode.
2)
Press
the
BAND
button
to
select
“EQ
USER”.
3)
Press
ENT
of
the
a-selector
[1]
when
the
“EQ
USER’
is
displayed.
4)
Slide
the
a-selector
[1]
to
<q
(left)
or
>
(right)
to
select
the
frequency
and
slide
to
A
(up)
or
‘WV
(down)
to
adjust
the
sound
level.
*
Repeat
the
above
procedures
to
set
the
char-
acteristics.
*
The
frequency
selection
option
differs
accord-
ing
to
the
connection
unit
as
follows:
Sound
level
to
DSP/EQ
|
Frequency
to
be
|
type
selected
be
adjusted
DPH9300
|
30/50Hz,
100Hz,
—12dB
to
+12dB
DPH7300
|
200Hz,
400Hz,
1kHz,
3kHz,
12kHz
30Hz,
60Hz,
120Hz,
|
—15dB
to
+15dB
200Hz
EQH5100
.
400Hz,
1kHz,
3kHz,
|
-12dB
to
+12dB
8kHz,
12kHz
5)
After
setting
the
characteristics,
press
and
hold
one
of
the
Preset
buttons
[9]
(No.
1
to
No.
6)
where
you
want
to
store
the
setting.
A
beep
sounds
when
the
setting
is
stored.
6)
Press
the
EQ
button
[14]
to
return
to
the
previ-
ous
mode.
Other
equalizer
settings
Basic
settings
The
following
items
can
be
set
for
the
equalizer.
¢
No.
of
sub
woofers:
STEREO/MONO/OFF
(SUB
WOOFER:
when
sub
woofers
are
connected)
¢
Lowest
frequency:
30
Hz/50
Hz
(EQ
MINFREQ:
when
the
DPH9300
or
DPH7300
is
connected)
¢
Parametric
equalizer
adjustment:
FRONT/REAR
/OFF
(P.
EQ:
when
the
DPH9300
is
connected)
¢
Turning
on
and
off
the
surround
effect:
ON/OFF
(SURROUND:
when
the
EQH5100
is
connected)
VRAX8370A
37
