American Sanders Operator's Manual - EZ-8 Sander HDTR Form No. 70399B - 41 -
EZ-8 Sander
Assembly Drawing #1 7/03
Ref. # Part No. Description Qty
1 40542A Cord, Motor 1
2 45602A Plug L6-15P 1
4 962831 Screw Set 10-32 x
5
/
16
3
5 170686 Nut Conduit ½ 1
6 61089A Pulley, Fan/Drum 1
7 80027A Screw
5
/
16
-18x1 Sq. Neck 6
8 50917A Belt, Fan 1
9 50916A Belt, Drum 1
10 22122A Cover, Fan 1
11 902567 Bearing 2
12 915561 Key, Hardened 2
13 920196 Nut ½-13 Jam 1
14 66159A Pulley, Fan 1
15 167312 Ring, Retaining 1
16 962798 Screw 10-24 x
1
/
2
3
17 67457A Shaft, Fan 1
18 980681 Washer, Bowed 1
19 877307 Ring, Retaining 1
20 65005A Impeller 1
21 60166A Axle, Truck 1
22 980648 Spacer 3
23 59945A Wheel 2
24 86113A Screw ½-13 x 2 1
25 920365 Nut
1
/
2
- 13 Nylock 2
26 80501A Key
3
/
16
x 1¼ 1
27 81211A Nut, Flanged
5
/
16
-18 2
28 962689 Screw Set ¼-28 x ¼ 4
29 66161A Pulley, Drum 1
30 86114A Screw ½-13 x 2½ 1
Ref. # Part No. Description Qty
31 915082 Key
3
/
16
x
3
/
16
x ¾ 1
32 51178A Bearing, Arbor 2
33 81211A Nut, Flanged
5
/
16
-18 4
34 67459A Shaft, Arbor Clamp 1
35 60434A Arm, Truck Level 1
36 85835A Screw ¼-20x 2½ 1
37 920196 Nut, ½-13 Jam 1
38 980645 Washer
3
/
8
SAE 2
39 60435A Arm, Truck, Lift 1
40 920110 Nut
5
/
16
-18 ESNA 1
41 65707A Link Adjust 1
42 58698A Spring, Truck Leveling 1
43 58699A Spring, Drum, Pressure 1
44 80026A Bolt, Shoulder
3
/
8
x ½ 1
45 920284 Nut ¼ ESNA 1
46 68015A Stud 2
47 61807A Spacer, Shim 1
48 82504A Pin, Clevis
5
/
16
x ¾ 1
49 25903A Frame, Main 1
50 81208A Nut Flanged
5
/
16
-24 2
51 44642A Motor, 1.5Hp 115V/60Hz 1
44648A Motor, 1.5 Hp 230V/50Hz 1
52 170637 Relief, Strain 1
53 915580 Key
3
/
16
x 1½ 1
54 57423A Ring, Retaining 1
55 77234A Label, Lifting Warning 1
56 51095A Cover, Capacitor 1
57 40545A Fan 1
Motor Parts Not Illustrated
Motor 44642A
Part No. Description Qty
41306A Capacitor Run 1
41307A Capacitor Start 1
47391A Thermal Switch 1
Motor 44648A
Part No. Description Qty
41308A Capacitor Run 1
41309A Capacitor Start 1
47392A Thermal Switch 1
