American Sanders Operator's Manual - EZ-8 Sander HDTR Form No. 70399B - 43 -
EZ-8 Sander
Assembly Parts List #2 8/10
Ref. # Part No. Description Qty
1 69106A Tube, Handle 1
2 61897A Tube, Dust 1
3 53741A Bag, Dust 1
4 68285A Support Tube 1
5 29918A Guard, Belt 1
6 962988 Screw ¼-20 x 1¼ 2
7 52125A Caster Asm. Complete 1
8 67612A Shoe, Dust 1
9 962826 Screw 10-24 x
3
/
8
4
10 32364A Cover, Drum 1
11 962823 Screw ¼-20x½ 13
12 65310A Key, Washer 1
13 920365 Nut
1
/
2
- 13 Nylock 3
14 85313C Screw 6-32 x
3
/
8
4
15 68613A Plate, End 1
16 162007 Clamp, Paper 1
17 962733 Screw 12-24 x 1 3
18 62711A Drum, Clamp Style 1
19 962170 Screw Set 10-24 x ¼ 1
20 66948A Retainer, Bumper 1
21 31223A Bumper, Front 1
22 22123A Cover, Front 1
23 64469A Handle, Front 1
24 61659A Collar 1
25 65706A Link, Control 1
26 960952 Bolt, Shoulder
3
/
8 x
3
/
8
2
27 34609A Grip, Lever 1
28 65618A Lever, control 1
29 980022 Washer, Wave 1
30 920110 Nut
5
/
16
-18 ESNA 1
31 980645 Washer
3
/
8
SAE 2
32 63928A Guard, Switch 1
33 34610A Grip, Handle 2
34 930093 Rivet
1
/
8
2
35 97100A Trim, Vinyl, Black Ref
36 74052A Plate Safety 1
37 40540A Cord Set, Power 115V 1
38 911248 Plug 5-15P 1
39 41807A Contactor 1
40 47387A Switch, Control 1
41 24525A Housing Control 1
42 81210A Nut, Fixture
3
/
8
PT 1
43 980675 Washer 1
44 962677 Screw 10-24 x
3
/
4
6
Ref. # Part No. Description Qty
45 962826 Screw 10-24 x
3
/
8
1
46 962109 Screw 10-24 x
5
/
8
2
47 337504 Relief, Strain 1
48 41708A Adapter L6 -15R 1
49 40543A Cord, Interconnect 1
50 51523A Relief, Strain 1
51 962094 Screw ¼-20 x
3
/
8
2
52 170892 Washer, ¼ Lock 2
53 920196 Nut, ½-13 Jam 1
54 980648 Washer ½ 1
55 55711A Latch 1
56* 920296 Nut #10 ESNA 2
57* 69098A Wear, Strip 1
58* 21011A Drum Expansion 1
10806A Recondition Expander
Drum, Complete 1
59 70488A Logo 1
60 65103A Insert 3
61# 56380352 Expander Drum Kit 1
includes 56-58, 69-72
62 59960A Wheel Caster 1
63 80012A Bolt, Shoulder
5
/
16
x 1½ 1
64 81307A Nut,
7
/
16
-14 Jam 1
65 67468A Shaft, Caster 1
66 51194B Bearing, Caster 2
67 29405A Yoke, Caster 1
68 920284 Nut, ¼-20 ESNA 1
69* 81217A Nut, ¼-20 x .218H Nylk. 2
70* 60906A Block, Wear 2
71* 962505 Screw, ¼-20 x
5
/
8
2
72* 77299A Label, Caution 1
73* 85381A Screw, 10-24 x
3
/
4
PN-SB 2
74 85517A Screw, 10-24 x ½ PN-SB 5
74* 85517A Screw, 10-24 x ½ PN-SB 3
75 980603 Washer, #10 Lock Ext. Th. 1
76* 68651A Plate Drum End 2
77 70175A Tag Warning 1
78 912169 Plug 1
79 911461 Connector 1
80 40541A Adapter Cord 1
81* 65311A Kit, Drum Asm. Expanding 1
82 30563A Adapter, 2” to 1½” 1
[ ]# 56380639 Decal-Prop 65 1
*NOTE: Equipped on sleeve units only
# = Revised or new since last update
Accessories Available:
13509A- Three hole-paper clamp bar, packaged with three clamp screws
