7/2014 A - 11 56091131 - CA30 17E
ENGLISH - AINSTRUCTIONS FOR USE
FIGURE 8
RECOVERY TANK EMPTYING
Turn off the machine.1.
Raise the squeegee assembly (14).2.
Move the machine to a dedicated draining location.3.
Grasp the handle (2) and tilt the machine backward until the guide wheel touches the 4.
fl oor.
Remove the drain hose from the clip, bend the top end of draining hose (A, Figure 8), and 5.
then remove the drain hose cap. Lower the hose to a low level or on the ground to drain
the water. Alternatively, place drain hose to a low position or on the ground to make the
water outlet face downward (B, Figure 8), and then twist open the drain cap to drain the
wastewater in the tank. After draining is completed, rinse the inside of recovery tank with
clean water
CAUTION !
When draining the wastewater, the drain hose must be folded or lowered to a lower
position (Figure 8 A or B), and the cap removed for wastewater to drain. Do not allow
the opening of the drain hose to face upward, as it could get wastewater on the
operator.
SOLUTION TANK EMPTYING
Complete Steps 1 to 4.6.
As shown in Figure 9, turn open the lid of Solution tank (A) counter clockwise (direction 7.
C), to drain Solution tank completely. Use clean water to rinse the inside of Solution tank.
When work is completed, replace the solution tank lid (A) by twisting in a clockwise in
direction (B).
AFTER EACH USE
When work is done and before leaving the machine, completes the following steps:
Remove the brush / pad holder.1.
Drain solution tank & rinse with clean water.2.
Drain recovery tank & rinse with clean water.3.
Complete the daily maintenance procedures. (see maintenance section)4.
Remove and rinse squeegee assembly with damp towel.5.
Keep recovery tank lid unsealed from tank to allow fresh air to circulate freely6.
USING FOR THE FIRST TIME
After the fi rst 9 hours of use, please check components to ensure all connections (electrical
& mechanical) are tight & check for any damage that may have occurred during operation.
Check for water leakage.
B
A
AA
C
B
FIGURE 9
