Clarke CA30 17E - Machine Components and Controls

A - 6 CA30 17E - 56091131 7/2014
INSTRUCTIONS FOR USEA - ENGLISH
MACHINE COMPONENTS
Safety switch button1.
Handle2.
Control panel3.
Serial number plate/Technical data4.
Control cover5.
N/A6.
N/A7.
Reset switch8.
Power Cable9.
Cover10.
Drain hose11.
Squeegee lift cable12.
N/A13.
Squeegee lift handle14.
Drain cap15.
Squeegee knob16.
Squeegee clip17.
Squeegee blade18.
Squeegee bracket19.
Squeegee adjusting knob20.
Squeegee rear support frame21.
Squeegee front support frame22.
Cup holder23.
Recovery tank cover handle24.
Recovery tank lid25.
Recovery tank26.
Solution fi ll27.
Brush deck28.
Brush / pad-holder29.
Vacuum motor30.
Brush motor31.
8” wheel32.
N/A33.
Vacuum tube34.
Electric Box35.
Float fi lter36.
Water level site tube37.
CONTROL PANEL
Power switch38.
Vacuum switch39.
Solution switch40.
