revised 9/14
Squeegee width 730mm
7/2014 A - 5 56091131 - CA30 17E
ENGLISH - AINSTRUCTIONS FOR USE
TECHNICAL DATA
Model CA30 17E
Machine Height 980mm
Solution tank capacity 50 litre
Recovery tank capacity 50 litre
Diameter of transport wheel 200mm
Diameter of guide wheel 63.5mm
Power of vacuum system motor 400w
Maximum gradient when working 2% (Max)
Sound pressure level at workstation 72dB(A) ±3dB(A)
Cable Length 20m
Vacuum system circuit capacity 1200 mm H
2
O
Cleaning width 430mm
machine maximum length 1060mm
Machine width without squeegee 480mm
Brush diameter 430mm
Weight with empty tanks 70kg
Gross weight of the machine ready for use 120kg
Brush motor power 750W
Brush speed 150rpm
Brush /pad-holder Maximum pressure 32kg(Max)
Packing size (Lx W x H) 1200 x 610 x 1170mm
