PARTS LIST
TANK SYSTEM
Item Ref. No. Qty Description
1 VF90412A 1 Handle, Recovery Tank Cover
2 VF90503A 1 Recovery Tank Cover
3 VA80758 3 Screw
4 VF90504 1 Gasket
5 VF90619A 1 Tank Filter Net Kit
6 VF90612A 1 Filter Cover
7 VF90614 1 Inlet Strap
8 VF90616 2 Screw Ta3.5x12
9 VA13483A 2 Washer
10 VA13477 2 Screw St4x15
11 VF90611 1 Filter Support
12 VF90519A 1 Tank (Cable Modle)
13 VF90011-CL 1 Logo Label
14 VF90613A 1 Floating Ball Of Water Level
15 VF90617 1 Inspection Tube
16 RD60764 2 Elbow,90º,Brass
17 VA80770 1 Gasket
18 VF90727 1 Vacuum Motor
19 VF85319 1 Acoustic Insulation Pipe
20 VF90523 1 Top Gasket Of Suction Motor
21 VF13503 1 Nut Lock M8
22 VF90511 1 Cover, Vacuum Motor
23 VF14543 3 Washer Ø6Ø18*1.5
24 VV13601 3 Washer,Lock,Ø5
25 VA52245 4 Scerew M5*15
26 VF14066 1 Nut M8
27 VF90434 1 Scerew M8*65
28 VF90513 1 Outlet O-Ring
29 VF90507 1 Outlet Cover
30 VF90312 1 2.5” Wheel Kit
31 VF14551 2 Ring D 17
32 VF90306 1 2.5” Wheel
33 VF90308 2 2.5” Hub Cap
Item Ref. No. Qty Description
34 VF90314 1 Transport Wheel Shaft
35 VV10116 1 Self-Locking Nylon Cable Ties
36 VF85102 1 Clamp
37 VF13604 1 Grooved Metal Gasket
38 VF90235 1 Scerew Tm4x10
39 VF90508 2 Suction Hose
40 VF90231 1 Gasket
41 VF90214 2 Seal Plate Cover
42 VF90217 2 Seal Plate
43 VV68303 4 Screw KT3.5x15
44 VF90529 1 Suction Tube Connecter
45 VF90528 1 Drain Hose Connector
46 VF90512 2 Suction Tube Gasket
47 VF90509 2 Sealing Knob
48 VA20304 4 Clamp
49 VF90534 1 Float Kit
50 VF90530 1 Cage,Float Complete
51 VF90526 1 Float Bracket
52 VF85124 1 Floate
53 VF90527 1 Floate Bracket Cover
54 VF90218 1 Control Seal Gasket
55 VF90401 1 Drain Hose Connecter
56 VF90443 1 Drain Hose-38
57 VF83150 1 Holder,”U”Hose
58 VF90701 1 17”Counter Weight Block
59 VF13534 4 Washer
60 VF13519 4 Washer,Lock,Ø8
61 VF14067 4 Screw M8*25
62 GT13054 4 Scerew Tm5x12
63 VF90814A 1 Battery Covery
64 VF90720 1 Vacuum Motor Connection Line
65 VF90730 1 Solenoid Valve Connection Line
66 VF90721 1 Brush Motor Connection Line
To Next Page
