Clarke CA30 17E - Page 47

7/2014 D - 5 56091131 - CA30 17E
PARTS LIST
CONTROL SYSTEM AND ELECTRICAL SYSTEM
Item Ref. No. Qty Description
1 VF90203A 2 Safety Switch Knob
2 VF90286 4 Screw KA3.5x12
3 VF90201A 1 Safety Switch Cover Left
4 VV68303 4 Screw KA3.5x15
5 VF90288 4 Washer Φ3.6xφ8x0.5
6 VF90210A 2 Switch Fix Frame
7 VV60153 3 Switch Rl2（P）
8 VF90009-CL 1 Decal Control Panel
9 VF90235 6 Screw Tm4x10
10 VF90204A 1 17” Switch Cover
11 VF90706 1 24vdc Regulator Board
12 VA14584 4 SCREW PB3.0x8
13 VF90285 1 Switch Seal Strip
14 VF90216 2 Switch Seal Bushing
15 VF90202 4 Spring
16 VF90252 2 Switch
17 VF90212A 1 Safety Switch Cover Right
18 VF90219 2 Gasket
19 VA13469 4 Screw Pb3x12
20 VF90213 2 Switch Seal Ring
21 GT13091 2 Screw,PB3.5x9.5mm
22 VF89042-3 1 Relay
23 GT13025 2 Screw,M3x12
24 VF90725-1 1 Running Capacitor
25 VF90815A 1 Cover Control Housing
26 GT13054 4 Screw Tm5x12
27 1 20” Serial Number Label
Item Ref. No. Qty Description
28 GV70034 1 Clamp Drain Hose
29 VF14538 2 SCREW ST3.5x16
30 VF90027-CL 1 Back Cover Panel
31 VF90129 1 Screw M5x20
32 VF90113 1 Handle Lift
33 VF14514 5 Nut Lock M5
34 VF90128 2 Screw M5
35 VF90114 1 Cable Squeegee Lift
36 VF89076 2 Circuit Breaker Cap
37 80407A 2 Screw M5x25
38 VF90116 1 Hand Bracket
39 VF90704 1 24v Relay
40 VV13652 2 Nut Lock M3
41 VV13653 4 Washer Ø3.4xø10x1.0mm
42 VF90232 1 Electric Support
43 VF90725-2 1 Start Capacitor
44 VF90259 1 Hand Fix Panel
45 VF99010C 1 Circuit Breaker
46 VF90517 1 Cable Fix Bracket
47 VF73705 1 Cable Sleeve
48 VF90745 1 Power Cord
49 VV67105 1 Connector
50 VF90703-US 1 Cable (20m)
51 VF422997 1 Hanging Board
52 VF13667 1 Screw M4x8
53 VF13604 1 Grooved Metal Gasket
54 VF90019 1 Brush Circuit Label
55 VF90747 1 Circuit Breaker
56 VF90020 1 Vacuum Circuit Label
