16
SPECIFICATIONS
PARTS AND SERVICING
Motor 230V, 50Hz, 1ph
Input Power 370 W
Fuse Rating 13A
Sanding Disc Diameter 6” (150 mm)
Sanding Belt Size (W x L) 4” x 36” (914 x 100 mm)
Sanding Belt Speed 450 m/min.
Sanding Table Dimensions (L x W) 225 x 160 mm
Table Angle Range 0-45 degrees
Mitre Guide Angle Range 0-60 degrees
Net Weight 18.65 kg
Dimensions (LxWxH) 447 x 363 x 255 mm
Sound Pressure Level dB L
pA
91.1 dB (A)
Sound Power Level dB L
WA
79.9 dB (A)
Vibration
3.34 m/s
2
Part No 6500413
For Parts & Servicing, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
