Clarke CS4-6E User Manual

18
EXPLODED DIAGRAM & PARTS LIST
NO DESCRIPTION
1 Phillips Screw + Flat
Washer M4x6
2Baseboard
3 Phillips Screw M4x8
4 Lock Washers 4
5 Phillips Screw St4.2x10
6Disc Cover
7 Disc Paper 150mm-80#
8 Socket Head Screw +
Lock Washer M6x16
9Disc
10 Wheel Box
11 Switch Box
12 Phillips Screw M5x8
13 Phillips Screw + Spring
Washer M5x25
14 Tension Lever Assy
15 Bush
16 Phillips Screw + Lock
Washer + Big Flat Washer
M5x16
17 Base
18 Phillips Screw M4X20
19 Connecting Box Cover
20 Phillips Screw St2.9x30
21 Relay 220v-240v
22 Tension Spring
23 Cotter Pin 1.6x10
24 Roll Pin 5x10
25 Phillips Screw + Spring
Washer + Flat Washer
M5x8
26 Phillips Screw M4x12
27 Hex Flange Nut M4
28 Capacitor 100uf/250v
29 Capacitor Support
30 Phillips Screw-plate
M4x12
31 Hex Head Bolt + Big Flat
Washer M6*12
32 Big Flat Washer 6
33 Work table Support
34 Miter Gauge Handle
35 Work table
36 Miter Slide
37 Miter Gauge Pointer
38 Miter Gauge
39 Switch Kjd20-2
40 Pressure Spring
41 Guard
42 Guide Shelf
43 External Circlip D12
44 Bearing 6001-2rs
45 Driven Roller
46 Driven Shaft
47 Phillips Screw M5*25
48 Capacitor Support
49 Capacitor 10uf/450v
50 Hex Nut-plate M8
51 Sanding Belt 100*915mm
52 Socket Head Screw +
Flat Washer M8x16
53 Support
54 Phillips Screw M5x16
55 Bearing Base
56 Belt Adjusting Handle
57 Rubber Washer
58 Adjusting Spring
59 Support Assy
60 Backstop
61 Drive roller
62 Inner Hex Lock Screw
M8x12
63 Drive Shaft
64 Bearing Cap
65 Support Cover
66 Phillips Screw M5x10
67 Belt Cover
NO DESCRIPTION
Quote Part Number
AWNCS46E + Diagram
number. e.g Tension
spring is AWNCS46E22
68 Phillips Screw + Special
Shaped Lock Washer
M5x16
69 Motor Shaft Wheel
70 Drive Belt
71 Driven Wheel
72 Phillips Screw + Spring
Washer + Flat Washer
M6x25
73 Socket Head Bolt M8x25
74 Belt Cover
75 Hex Nut M8
76 Anti Bending Tail Sleeve
77 Plate 150l
78 Cable Clamp
79 Phillips Screw M5*20
80 Dust Collecting Cover
81 Front End Housing
82 Phillips Screw - Plate
M6*113
83 Retainer 90#
84 Bearing 6003-2rs
85 Stator Wire Package
86 Rotor
87 Wave Spring Washer 35
88 Rear End Cover
89 Spring Washer
90 Hex Nut-plate M6
91 Hex Bolt + Spring Washer
M6x20
92 External Circlip D17
93 Power Cable
94 Protection Plate
95 Socket Head Wrench
M6x90x32
NO DESCRIPTION
