Clarke Fusion 20 Troubleshooting Guide

28
NOTE: If you do not remove this spring at this time you will damage the spring and it will
have to be replaced with a new spring.
Step 9.
This spring is located at the rear of the Pad
Motor Assy. and must be removed at this time
and reinstalled at the same time during
reinstallation.
With the Burnisher lowered back down to the
floor, use a 3/16” Allen® wrench to remove the
screw on each side of the Pad Motor Assembly
