Key to Figure 3: Eclipse HX-Median rear panel
Feature
Description
A
IEC power supply connectors. For more information about the twin power
supplies, see 3.2.2
Power supplies.
B
Spare slots for interface card rear connector panels. All front installed
interface cards require a corresponding rear connector panel. Blank panels can
be installed to unused slots.
The Eclipse HX-Median has 7 slots available for interface cards. For more
information, see 3.4
Interface cards.
C
MVX-A16 analog interface card rear connector panel.
An MVX-A16 rear connector panel has 16 RJ-45 connectors for connecting
intercom panels and interfaces. For more information about MVX-A16 cards,
see 3.3.2
MVX-A16 analog port card.
D
CPU card rear panel. The CPU card rear panel houses connectors for an
external PC, network, interfaces, alarms and other matrices.
Up to 2 CPU cards can be installed to the matrix, but only one rear-panel CPU
card is required. Whichever of the two front-installed CPU cards is acting as
master will work in conjunction with this card. For more information, see
3.3.1
CPU card.
E
Interface module slots. The Eclipse HX-Median has 8 built-in interface module
slots. For more information, see 3.5
Interface modules.
Table 4: Key to Figure 3: Eclipse HX-Median rear panel
