12.1 Matrix frame capabilities
Category
Number / Comments
Maximum Expansion Cards
7
Ports per MVX Port Card
16
Maximum MVX Port Cards
7
Maximum CPU Cards
2 (included)
Maximum Fibre Expansion Cards
2
Maximum E-Que or IVC-32 or
LMC-64 Expansion Cards
4 (in total)
Maximum Power Supply Units
2 (included)
Maximum RJ-45 Ports per Matrix
112
Maximum Timeslots
512
Table 26: Matrix frame capabilities
12.2 Mechanical
Category
Measures / comments
Height
10.6 inches (267 mm or 6 RU)
Width
19 inches (482 mm)
Depth
16 inches (410 mm)
Front Card Depth
300 mm
Weight
20 to 35 kg
Table 27: Mechanical
