12.3 Environmental
Category
Measures / comments
Operating Temperature
0º C to +40º C, ambient
Storage Temperature
-55º C to +70º C
Humidity, Maximum
90% non-condensing
Table 28: Environmental
12.4 Matrix frame performance
Category
Measures / Comments
Sample Rate
48 kHz
Resolution
24 bit
Frequency Response
@ 48 kHz sampling
30 Hz – 22 kHz ± 3 dBu
Crosstalk (adjacent channel)
<–70 dBu
Nominal Level
0 dBu
Matrix headroom
+18 dBu
Distortion
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
Off Noise
<–70 dBu (20 Hz - 22kHz)
On Noise
<–65 dBu (20 Hz - 22 kHz)
Key Response, Intra-System
<40 ms for audio route
Table 29: Matrix frame capabilities
12.5 E-MADI64 interface front card
Category
Measures / comments
Height
6RU
Depth
300 mm
Operating Temperature
0º C to +40º C
Storage Temperature
-55º C to +70º C
Humidity
40 - 90% non-condensing
Power
+3.3V
Table 30: E-MADI64 interface front card
