12.6 E-MADI64 interface rear card
Category
Measures / comments
Height
6RU
Depth
58mm (max)
Operating Temperature
0º C to +40º C
Storage Temperature
-55º C to +70º C
Humidity
40 - 90% non-condensing
Power
+3.3V
Table 31: E-MADI64 interface rear card
12.7 E-MADI64 fiber cable
Category
Measures / comments
Fiber cable
Multimode 62.5/125µm
Coaxial cable
75ohm
Table 32: E-MADI64 fiber cable
12.8 E-MADI64 fiber transceiver
Category
Measures / comments
Type
Multimode SFP Transceiver
Wavelength
1310nm
Connector
Duplex LC
Standard Max Node Length
2km (other distances (achieved using the
optional single mode fiber module) are available
to special order.)
Table 33: E-MADI64 fiber transceiver
Table note:
The standard multimode fiber module is a Class 1 LED Product . The optional single mode fiber
module is a
Class 1 Laser Product .
