To activate the embedded configuration:
1. On the front of the CPU card, press and hold the CONFIG and the ENG buttons.
2. Simultaneously, reset the CPU card by pressing and holding the CPU card’s lower
RESET button (the Full reset button).
Note:
A tool, such as a pin, is used to press and hold the RESET button.
3. Continue holding the CONFIG, ENG and RESET buttons until the CPU card’s dot
matrix display displays 0. It may take 1 - 2 seconds before 0 is displayed.
The embedded configuration has now been activated.
To deactivate the embedded configuration, perform a CPU card reset.
The configuration (1, 2, 3 or 4) that was previously active on the CPU card replaces the
embedded configuration as the active configuration.
62
Eclipse HX-Median User Guide
