English - 23 -
UART 1
Select ASCII/HEX protocol for UART 1. Default value is HEX. There is no need to
restart the Display after selection in order to work with the protocols correctly. If the
the Display is booted up.
Note that ASCII/HEX selection is always working as expected. It does not matter if the
debug logs are enabled or not.
Also note that HEX protocol will work with the baud rate value 9600 for UART1
(Optional)
Sets the source option for these funtions. AutoDisplay and Android options will be
available.
Menu lock
You can block the usage of the menu button on the remote by setting this item as All
menus
to disable this function.
Auto Source
Switch
If this option is enabled the Display will switch to the currently active HDMI source
automatically when a device is connected to the Display through the HDMI1 or
HDMI2 input socket. Set as Enabled to enable this feature.
When the HDMI source is removed the Display will switch to other active HDMI
source. If there isn't any other device connected to the Display and the HDMI Wake
UP option for the related HDMI source is enabled the Display will switch into the
standby mode.
There is also a 3-second restriction for the successive connected HDMI sources.
device is plugged in.
Note: This feature applies for HDMI1 and HDMI2 input sockets only. Refer to the
General View section to see the HDMI inputs.
Power Up Settings
Power Up Mode
Last State, Always On and Standby
options are available.
Quick Standy
If this feature is enabled the Display can be turned on again
commands Left or Right button to enable or disable
the feature.
Power on Delay
Sets a delay value at power on. This value can be set from 0 to 2000 ms in steps of 100
ms. The Display will turn on after the set delay time is expired.
Auto Launch
CMS(Start url)Open Browser(Open Browser
initial page) and Disabled options are available.
Boot Up Picture
Mode
the last set picture
mode will be used at power on.
HDMI1 Wake Up
If this option is set as Enabled
when it is switched on. This feature works based on HDMI 5V signal. When this signal
is active the Display wakes up and when the signal is inactive the Display shuts down.
You can disable this option by setting as Disabled.
In order to use this feature in
conjunction with the Auto Source Switch feature it is recommended to enable the
Auto Source Switch option in the Signage>Controls menu.
If any Scheduler is set this option will be inactive and can not be set as Enabled.
Note: This feature may not be available depending on the model of your unit.
HDMI2, HDMI3,
HDMI4 Wake Up
(optional)
If this option is set as Enabled
on. This feature works based on HDMI 5V signal. When this signal is active the Display
wakes up and when the signal is inactive the Display shuts down. You can disable this
option by setting as Disabled.
In order to use this feature in conjunction with the
Auto Source Switch feature it is recommended to enable the Auto Source Switch
option in the Signage>Controls menu.
If any Scheduler is set this option will be inactive and can not be set as Enabled.
Note: This feature or HDMI3 and HDMI4 options may not be available depending on the model of your
unit. If multiple devices are connected to the Display through HDMI input sockets, this feature will not work.
