Clevo C4505 - Page 101

Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 5
6
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the hard disk bay cover and loosen screws & .
3. Remove the hard disk bay cover .
Figure 6 - 2
Hard Disk Bay
Cover Removal
1
2
3
21
3
