Installation Instructions
Single Stage Heat Pump with AUX Heat
1
GAS
O
GAS/EL
ELEC
B
HP
ON
23
1
GAS
O
GAS/EL
ELEC
B
HP
ON
23
Dip Switch Settings
Thermostat
Single Stage Unit, CXM
Y
W
O
G
R
C
AL1
AL2
A
D / H RS R G Y1 W O Y2 C CK1
Note: Do not clip jumper JW1 on CXM board
