Table 7: Humidistat/Dehumidistat Logic & DXM (2.1, 2.2., 2.3) DIP Settings
Sensor 2.1 2.2 2.3 Logic Reheat (ON) - H Reheat (OFF) - H
Humidistat
OFF OFF OFF Reverse 0 VAC 24 VAC
Dehumidistat
OFF ON OFF Standard 24 VAC 0 VAC
1
Cooling input takes priority over dehumidify input.
2
DXM is programmed to ignore the H demand when the unit is in heating mode.
3
N/A for single stage units; Full load operation for dual capacity units.
4
ON/OFF = Either ON or OFF.
Mode
Input Output
O G Y1 Y2
3
HOGY1Y2
3
Reheat
No Demand
ON/OFF OFF OFF OFF OFF ON/OFF OFF OFF OFF OFF
Fan Only
ON/OFF ON OFF OFF OFF ON/OFF ON OFF OFF OFF
Cooling 1st Stage
ON ON ON OFF OFF ON ON ON OFF OFF
Cooling 2nd Stage
ON ON ON ON OFF ON ON ON ON OFF
Cooling & Dehumidistat
1
ON ON ON ON/OFF ON ON ON ON ON/OFF OFF
Dehumidistat Only
ON/OFF OFF OFF OFF ON ON ON ON ON ON
Heating 1st Stage
OFF ON ON OFF OFF OFF ON ON OFF OFF
Heating 2nd Stage
OFF ON ON ON OFF OFF ON ON ON OFF
Heating & Dehumidistat
2
OFF ON ON ON/OFF ON OFF ON ON ON/OFF OFF
Table 8: ClimaDry
®
Operating Modes
ClimaDry
®
Modulating Reheat Option
UNIT STARTING AND OPERATING CONDITIONS
Operating Limits
Environment – Units are designed for indoor installation only. Never install units in areas subject to freezing or where
humidity levels could cause cabinet condensation (such as unconditioned spaces subject to 100% outside air).
Power Supply – A voltage variation of +/– 10% of nameplate utilization voltage is acceptable.
Determination of operating limits is dependent primarily upon three factors: 1) return air temperature. 2) water
temperature, and 3) ambient temperature. When any one of these factors is at minimum or maximum levels, the
other two factors should be at normal levels to ensure proper unit operation. Extreme variations in temperature and
humidity and/or corrosive water or air will adversely affect unit performance, reliability, and service life. Consult Table
9a for operating limits.
Table 9a: Operating Limits
Cooling Heating
Air Limits
Min. ambient air, DB 45ºF [7ºC] 39ºF [4ºC]
Rated ambient air, DB 80.6ºF [27ºC] 68ºF [20ºC]
Max. ambient air, DB 130ºF [54.4ºC] 85ºF [29ºC]
Min. entering air, DB/WB
*60/45ºF [16/7ºC] 40ºF [4.4ºC]
Rated entering air, DB/WB 80.6/66.2ºF [27/19ºC] 68ºF [20ºC]
Max. entering air, DB/WB 100/75ºF [38/24ºC] 80ºF [27ºC]
Water Limits
Min. entering water 30ºF [-1ºC] 20ºF [-6.7ºC]
Normal entering water 50-110ºF [10-43ºC] 30-70ºF [-1 to 21ºC]
Max. entering water 120ºF [49ºC] 90ºF [32ºC]
TT
Operating Limits
Normal Water Flow
1.5 to 3.0 gpm / ton
[1.6 to 3.2 l/m per kW]
*If with ClimaDry
®
65/55°
