Unit Physical Data
Tranquility
®
30 Two-Stage (TT) Series (60Hz Only)
Model 026 038 049 064 072
Compressor (1 Each) Two-Stage Scroll
Factory Charge (HFC-410A) (oz) [kg] 60 [1.70] 64 [1.81] 81 [2.30] 142 [4.03] 140 [3.97]
ECM Fan Motor & Blower
Fan Motor (hp) [W] 1/2 [373] 1/2 [373] 1 [746] 1 [746] 1 [746]
Blower Wheel Size (dia x w) -
(in) [mm]
9 x 7
[229 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Water Connection Size
FPT (in) 3/4 3/4 1 1 1
HWG Connection Size
FPT (in) 1/2 1/2 1/2 1/2 1/2
Coax Volume
Volume (US Gallons) [liters] 0.76 [2.88] 0.92 [3.48] 1.24 [4.69] 1.56 [5.91] 1.56 [5.91]
Vertical Upfl ow/Downfl ow
Air Coil Dimensions (h x w) - (in) [mm]
28 x 20
[711 x 508]
28 x 25
[711 x 635]
32 x 25
[813 x 635]
36 x 25
[914 x 635]
36 x 25
[914 x 635]
Standard Filter - 1” [25.4mm]
Throwaway, qty (in) [mm]
28 x 24
[711 x 610]
28 x 30
[711 x 762]
2 - 16 x 30
[406 x 762]
1 - 16 x 30
[813 x 762]
1 - 20 x 30
[508 x 762]
1 - 16 x 30
[813 x 762]
1 - 20 x 30
[508 x 762]
Weight - Operating, (lbs) [kg] 266 [121] 327 [148] 416 [189] 443 [201] 443 [201]
Weight - Packaged, (lbs) [kg] 276 [125] 337 [153] 426 [193] 453 [205] 453 [205]
Horizontal
Air Coil Dimensions (h x w) - (in) [mm]
18 x 31
[457 x 787]
20 x 35
[508 x 889]
20 x 40
[508 x 1016]
20 x 45
[508 x 1143]
20 x 45
[508 x 1143]
Standard Filter - 1” [25.4mm]
Throwaway, qty (in) [mm]
2 - 18 x 18
[457 x 457]
1 - 12 x 20
[305 x 508]
1 - 20 x 25
[508 x 635]
1 - 18 x 20
[457 x 508]
1 - 20 x 24
[508 x 610]
2 - 20 x 24
[508 x 610]
2 - 20 x 24
[508 x 610]
Weight - Operating, (lbs) [kg] 266 [121] 327 [148] 416 [189] 443 [201] 443 [201]
Weight - Packaged, (lbs) [kg] 276 [125] 337 [153] 426 [193] 453 [205] 453 [205]
Notes:
All units have TXV expansion device and 1/2” & 3/4” electrical knockouts.
575 volt motors are two speed.
For units with ClimaDry
®
option add 66lbs (30kg) to weights.
Unit Maximum Water Working Pressure
Options
Max Pressure PSIG [kPa]
Base Unit
300 [2,068]
Internal Secondary Pump (ISP)
145 [999]
ClimaDry
®
145 [999]
Internal Motorized Water Valve (MWV)
300 [2,068]
Internal Auto Flow Valve
300 [2,068]
Use the lowest maximum pressure rating when multiple options are combined.
