ClimateMaster Tranquility TY Series - Ground-Loop and Ground Water Heat Pump Applications

Tranquility
®
22
(
TY
)
Series
Rev.: July 8, 2021
ClimateMaster Water-Source Heat Pumps
16
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
High and
Low Voltage
Knockouts
Vibration Isolation Pad
To Thermostat
Shut Off
Ball Valves
for Isolation
Water Out
Water In
Ground-Loop and Ground Water Heat Pump Applications
Ground Water Heat Pump Applications
Typical Open Loop/Well
High and
Low Voltage
Knockouts
Vibration Isolation Pad
To Thermostat
Shut Off
Ball Valves
for Isolation
Water In
Pressure
Tank
Optional
Filter
Water Out
Boiler
Drains
Ground-Loop Heat Pump Applications
Typical Closed Loop with Central Pumping
