CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Unit Physical Data
Tranquility
®
22 Two-Stage (TY) Series (60 Hz)
Model 024 030 036 042 048 060
Compressor (1 Each) Scroll Scroll Scroll Scroll Scroll Scroll
Factory Charge HFC-410A (oz) 49 48 48 70 80 80
ECM Fan Motor & Blower
Fan Motor (hp) [W] 1/2 1/2 1/2 3/4 3/4 1
Blower Wheel Size (dia x w) - (in) [mm] 9X7 9X7 9X8 9X8 10X10 11X10
Water Connection Size
FPT (in) 3/4" 3/4" 3/4" 3/4" 1" 1"
Coax Volume (gallons) 0.323 0.323 0.738 0.89 0.738 0.939
Vertical Upow
Air Coil Dimensions (h x w) - (in) [mm] 20 X 17.25 20 X 17.25 24 X 21.75 24 X 21.75 24x28.25 24x28.25
Standard Filter - 1" [25.4mm] Throwaway,
qty (in) [mm]
20x20 20x20 24x24 24x24
1-14x24
1-18x24
1-14x24
1-18x24
Weight - Operating, (lbs) [kg] 189 197 203 218 263 278
Weight - Packaged, (lbs) [kg] 194 202 209 224 270 285
Horizontal
Air Coil Dimensions (h x w) - (in) [mm] 16 X 22 16 X 22 20 X 25 20 X 25 20 X 35 20 X 35
Standard Filter - 1" [25.4mm] Throwaway,
qty (in) [mm]
18x25 18x25 2-14x20 2-14x20 1-20x24 1-14x20 1-20x24 1-14x20
Weight - Operating, (lbs) [kg] 174 182 203 218 263 278
Weight - Packaged, (lbs) [kg] 179 187 209 224 270 285
Notes:
All units have TXV expansion device and 1/2” & 3/4” electrical knockouts.
Condensate drain connection is rubber coupling that couples to 3/4” schedule 50/80 PVC.
Unit Maximum Water Working Pressure
Options
Max Pressure PSIG [kPa]
Base Unit
500 [3,447]
